INA SX011824-A-VSP Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 24,171.80 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
120 |
| Dış (D) MM |
150 |
| En (B) MM |
16 |
| İç (d) Inch |
4.7244 |
| Dış (D) Inch |
5.9055 |
| En (B) Inch |
0.6299 |
| Ağırlık |
0.8 kg
|
Data from Schaeffler (medias)
| Outside Diameter (D a) mm |
150 |
| Height of the assembled bearing (H) mm |
16 |
| ECLASS number |
23-05-12-05 |
| ECLASS2 number |
23-05-12-05 |
Suffix description
| A |
|
| VSP |
For Mounting With An Axially Supported L-Section Ring In Series YRT. In Fitting Of The Series Yrt With An L-Section Ring Supported Axially Over Its Whole Surface, There Is An Increase In The Axial Rigidity In The Direction Of The Support Ring As A Function Of The Support Ring Rigidity And In The Tilting Rigidity Of Up To 20%. In This Case, Delivery With A Different Preload Match Is Necessary |
