INA SX011824-A-VSP

Özellikler

Marka	INA
Ürün No	SX011824-A-VSP INA
Üretici No	0071373540079
EAN	4047643190527
Kategori	Özel Ürünler

Ağırlık ve Boyutlar

İç (d) MM	120
Dış (D) MM	150
En (B) MM	16
İç (d) Inch	4.7244
Dış (D) Inch	5.9055
En (B) Inch	0.6299
Ağırlık	0.8 kg

Data from Schaeffler (medias)

Outside Diameter (D a) mm	150
Height of the assembled bearing (H) mm	16
ECLASS number	23-05-12-05
ECLASS2 number	23-05-12-05

Suffix description

A
VSP	For Mounting With An Axially Supported L-Section Ring In Series YRT. In Fitting Of The Series Yrt With An L-Section Ring Supported Axially Over Its Whole Surface, There Is An Increase In The Axial Rigidity In The Direction Of The Support Ring As A Function Of The Support Ring Rigidity And In The Tilting Rigidity Of Up To 20%. In This Case, Delivery With A Different Preload Match Is Necessary
