INA PWKRE72-2RS-RR-XL Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 5,476.80 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
28 |
| Dış (D) MM |
72 |
| En (B) MM |
28 |
| İç (d) Inch |
1.1024 |
| Dış (D) Inch |
2.8346 |
| En (B) Inch |
1.1024 |
| Ağırlık |
1.05 kg
|
Ürün Özellikleri
| Fok |
2RS - İki Tarafta Kauçuk Conta |
| Excenterring |
E - Excenterring with Inbus Mount |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Fit diameter of roller stud / stud (d 1) mm |
24 |
| Genişlik (b) mm |
80 |
| Basic dynamic load rating, radial (C r w) |
39000 |
| Temel statik yük derecesi, radyal (C 0r) |
53000 |
| Speed on permanent grease lubrication (n D G) |
2200 |
| ECLASS number |
23-05-15-02 |
| ECLASS2 number |
23-05-15-02 |
| Medias description |
Yoke type track roller PWKRE..-2RS-RR-XL, full complement roller set, two-row, with axial guidance, with eccentric, pallet changer |
Suffix description
| 2RS |
Rubber Seals At Each Side Of The Bearing, Temperature Range -30u2103/+120u2103 |
| RR |
Protected Against Corrosion By Corrotect® Special Coating |
| XL |
X-Life |
