INA PWKRE72-2RS-RR-XL

Özellikler

Marka	INA
Ürün No	PWKRE72-2RS-RR-XL INA
Üretici No	0645547750000
Alternatif Kodu	PWKRE72-2RS-RR
EAN	4054366811219
Kategori	Kam Takipçisi

Ağırlık ve Boyutlar

İç (d) MM	28
Dış (D) MM	72
En (B) MM	28
İç (d) Inch	1.1024
Dış (D) Inch	2.8346
En (B) Inch	1.1024
Ağırlık	1.05 kg

Ürün Özellikleri

Fok	2RS - İki Tarafta Kauçuk Conta
Excenterring	E - Excenterring with Inbus Mount
Running Surface	Standard

Data from Schaeffler (medias)

Fit diameter of roller stud / stud (d 1) mm	24
Genişlik (b) mm	80
Basic dynamic load rating, radial (C r w)	39000
Temel statik yük derecesi, radyal (C 0r)	53000
Speed on permanent grease lubrication (n D G)	2200
ECLASS number	23-05-15-02
ECLASS2 number	23-05-15-02
Medias description	Yoke type track roller PWKRE..-2RS-RR-XL, full complement roller set, two-row, with axial guidance, with eccentric, pallet changer

Suffix description

2RS	Rubber Seals At Each Side Of The Bearing, Temperature Range -30u2103/+120u2103
RR	Protected Against Corrosion By Corrotect® Special Coating
XL	X-Life
