INA HFL1626-L564 Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 518.40 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
16 |
| Dış (D) MM |
22 |
| En (B) MM |
26 |
| İç (d) Inch |
0.6299 |
| Dış (D) Inch |
0.8661 |
| En (B) Inch |
1.0236 |
| Ağırlık |
0.022 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Under roller diameter (F w) mm |
16 |
| Radial Static Load Rating C0r (N) |
9000 |
| Radial Dynamic Load Rating Cr (N) |
7400 |
| Temel statik yük derecesi, radyal (C 0r) |
"9000.0000" |
| Limiting speed for rotating shaft (n GW) |
8500 |
| Limiting speed for rotating outer ring (n GA) |
7500 |
| ECLASS number |
23-05-21-90 |
| ECLASS2 number |
23-05-21-90 |
| Medias description |
Drawn cup roller clutch HFL, with bearing |
Suffix description
| L564 |
Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication |
