INA HFL1626-L564

Özellikler

Marka	INA
Ürün No	HFL1626-L564 INA
Üretici No	0016002060962
Alternatif Kodu	HFL1626
EAN	4012802369274
Kategori	İğne Makaralı ve Kafes Tertibatı

Ağırlık ve Boyutlar

İç (d) MM	16
Dış (D) MM	22
En (B) MM	26
İç (d) Inch	0.6299
Dış (D) Inch	0.8661
En (B) Inch	1.0236
Ağırlık	0.022 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Under roller diameter (F w) mm	16
Radial Static Load Rating C0r (N)	9000
Radial Dynamic Load Rating Cr (N)	7400
Temel statik yük derecesi, radyal (C 0r)	"9000.0000"
Limiting speed for rotating shaft (n GW)	8500
Limiting speed for rotating outer ring (n GA)	7500
ECLASS number	23-05-21-90
ECLASS2 number	23-05-21-90
Medias description	Drawn cup roller clutch HFL, with bearing

Suffix description

L564	Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
