INA GE100-DO-2RS-C3 Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 8,054.20 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
100 |
| Dış (D) MM |
150 |
| En (B) MM |
70 |
| İç (d) Inch |
3.937 |
| Dış (D) Inch |
5.9055 |
| En (B) Inch |
2.7559 |
| Ağırlık |
4.4 kg
|
Ürün Özellikleri
| Fok |
2RS - İki Tarafta Kauçuk Conta |
| Contact Material |
Steel on Steel |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
150 |
| Radial Static Load Rating C0r (N) |
3040000 |
| Width inner ring (B) mm |
70 |
| Radial Dynamic Load Rating Cr (N) |
608000 |
| Temel statik yük derecesi, radyal (C 0r) |
"2900000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Radial spherical plain bearing, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-1, dimension series E, sealed |
Suffix description
| DO |
Sliding Contact Surface Steel/Steel & Inner And Outer Ring Hardened |
| 2RS |
Lip Seals On Both Sides |
| C3 |
Radial Internal Clearance Larger Than Normal (For Spherical Plain Bearings Requiring Maintenance) |
