INA GE100-DO-2RS-C3
Fiyatı: 8,054.20 ₺
Özellikler
| Marka | INA |
| Ürün No | GE100-DO-2RS-C3 INA |
| Üretici No | 0066482900030 |
| EAN | 4012802530971 |
| Kategori | Küresel Düz Yatak |
| İç (d) MM | 100 |
| Dış (D) MM | 150 |
| En (B) MM | 70 |
| İç (d) Inch | 3.937 |
| Dış (D) Inch | 5.9055 |
| En (B) Inch | 2.7559 |
| Ağırlık | 4.4 kg |
| Fok | 2RS - İki Tarafta Kauçuk Conta |
| Contact Material | Steel on Steel |
| Outside diameter bearing (D) mm | 150 |
| Radial Static Load Rating C0r (N) | 3040000 |
| Width inner ring (B) mm | 70 |
| Radial Dynamic Load Rating Cr (N) | 608000 |
| Temel statik yük derecesi, radyal (C 0r) | "2900000.0000" |
| ECLASS number | 23-05-01-06 |
| ECLASS2 number | 23-05-01-06 |
| Medias description | Radial spherical plain bearing, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-1, dimension series E, sealed |
| DO | Sliding Contact Surface Steel/Steel & Inner And Outer Ring Hardened |
| 2RS | Lip Seals On Both Sides |
| C3 | Radial Internal Clearance Larger Than Normal (For Spherical Plain Bearings Requiring Maintenance) |
