INA E35-KLL-NR-AH01-OSE Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 1,623.60 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
35 |
| Dış (D) MM |
72 |
| En (B) MM |
51,3 |
| İç (d) Inch |
1.378 |
| Dış (D) Inch |
2.8346 |
| En (B) Inch |
2.0197 |
| Ağırlık |
0.55 kg
|
Ürün Özellikleri
| Fok |
2L - Her İki Tarafta LS Contası |
| Yağlama |
Standart Yağlama |
| Özel Muamele |
No Special Treatment |
Data from Schaeffler (medias)
| ECLASS number |
23-05-08-02 |
| ECLASS2 number |
23-05-08-02 |
Suffix description
| K |
Conrad (Non-Filling Slot) Type |
| LL |
Labyrinth Seals On Both Sides (L Type Seal - All Parts Of The L Type Seal Are Zinc Plated On All Sides In Order To Improve Corrosion Protection - No Seal Friction) |
| NR |
Slot And Snap Ring For Radial Insert Ball Bearings With Cylindrical Outer Ring |
| AH01 |
Dimensions Can Deviate From Basic Part Number, Internal Clearance Is C3 (Larger Than Normal) and Protected Against Corrosion By Corrotect® Special Coating |
| OSE |
Bearing Without Locking Element (Eccentric Locking Collar) |
