INA E35-KLL-NR-AH01-OSE

Özellikler

Marka	INA
Ürün No	E35-KLL-NR-AH01-OSE INA
Üretici No	0035605970000
EAN	4012802822342
Kategori	Muhafazalar İçin Rulmanlar

Ağırlık ve Boyutlar

İç (d) MM	35
Dış (D) MM	72
En (B) MM	51,3
İç (d) Inch	1.378
Dış (D) Inch	2.8346
En (B) Inch	2.0197
Ağırlık	0.55 kg

Ürün Özellikleri

Fok	2L - Her İki Tarafta LS Contası
Yağlama	Standart Yağlama
Özel Muamele	No Special Treatment

Data from Schaeffler (medias)

ECLASS number	23-05-08-02
ECLASS2 number	23-05-08-02

Suffix description

K	Conrad (Non-Filling Slot) Type
LL	Labyrinth Seals On Both Sides (L Type Seal - All Parts Of The L Type Seal Are Zinc Plated On All Sides In Order To Improve Corrosion Protection - No Seal Friction)
NR	Slot And Snap Ring For Radial Insert Ball Bearings With Cylindrical Outer Ring
AH01	Dimensions Can Deviate From Basic Part Number, Internal Clearance Is C3 (Larger Than Normal) and Protected Against Corrosion By Corrotect® Special Coating
OSE	Bearing Without Locking Element (Eccentric Locking Collar)
