FAG HCM71914-C-T-P4S-UL-XL Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 13,353.00 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
70 |
| Dış (D) MM |
100 |
| En (B) MM |
16 |
| İç (d) Inch |
2.7559 |
| Dış (D) Inch |
3.937 |
| En (B) Inch |
0.6299 |
| Ağırlık |
0.255 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Kasa Tipi |
TB - Sert Fiber Kafes |
| Kesinlik |
P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle |
15 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
Data from Schaeffler (medias)
| Genişlik (b) mm |
16 |
| Temel statik yük derecesi, radyal (C 0r) |
15000 |
| Limiting speed for grease lubrication (n G Grease) |
24200 |
| Limiting speed for oil lubrication (n G Oil) |
35300 |
Suffix description
| C |
15° Or 17° Contact Angle |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S |
Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UL |
Single Bearing, Universal, Light Preload |
| XL |
X-Life |
