FAG HCM71914-C-T-P4S-UL-XL
Fiyatı: 13,353.00 ₺
Özellikler
| Marka | FAG |
| Ürün No | HCM71914-C-T-P4S-UL-XL FAG |
| Üretici No | 0924550000000 |
| Alternatif Kodu |
71914CEGA/HCP4A |
| EAN | 4054369761535 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 70 |
| Dış (D) MM | 100 |
| En (B) MM | 16 |
| İç (d) Inch | 2.7559 |
| Dış (D) Inch | 3.937 |
| En (B) Inch | 0.6299 |
| Ağırlık | 0.255 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle | 15 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Genişlik (b) mm | 16 |
| Temel statik yük derecesi, radyal (C 0r) | 15000 |
| Limiting speed for grease lubrication (n G Grease) | 24200 |
| Limiting speed for oil lubrication (n G Oil) | 35300 |
| C | 15° Or 17° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UL | Single Bearing, Universal, Light Preload |
| XL | X-Life |
