FAG HCB7211-C-2RSD-T-P4S-UL-L298 Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 21,934.00 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
55 |
| Dış (D) MM |
100 |
| En (B) MM |
21 |
| İç (d) Inch |
2.1654 |
| Dış (D) Inch |
3.937 |
| En (B) Inch |
0.8268 |
| Ağırlık |
0.55 kg
|
Ürün Özellikleri
| Fok |
2RU - İki Conta / Temassız Tip |
| Kasa Tipi |
TB - Sert Fiber Kafes |
| Kesinlik |
P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle |
15 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Yağlama |
Standart Yağlama |
Data from Schaeffler (medias)
| Genişlik (b) mm |
21 |
| Temel statik yük derecesi, radyal (C 0r) |
25000 |
| Limiting speed for grease lubrication (n G Grease) |
18000 |
Suffix description
| C |
15° Or 17° Contact Angle |
| 2RSD |
Lip Seals On Both Sides, Non-Contact |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S |
Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UL |
Single Bearing, Universal, Light Preload |
| L298 |
High Temperature Grease That, Due To Its Higher Base Oil Viscosity, Is Used At Continuous Temperatures Up To Approx. +110°C |
