FAG HCB7211-C-2RSD-T-P4S-UL-L298

Özellikler

Marka	FAG
Ürün No	HCB7211-C-2RSD-T-P4S-UL-L298 FAG
Üretici No	0848622200000
EAN	4054364482015
Kategori	Tek Sıra - Açısal Temaslı

Ağırlık ve Boyutlar

İç (d) MM	55
Dış (D) MM	100
En (B) MM	21
İç (d) Inch	2.1654
Dış (D) Inch	3.937
En (B) Inch	0.8268
Ağırlık	0.55 kg

Ürün Özellikleri

Fok	2RU - İki Conta / Temassız Tip
Kasa Tipi	TB - Sert Fiber Kafes
Kesinlik	P4S Hassasiyet (P4ten Yüksek)
Contact Angle	15 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama	Standart Yağlama

Data from Schaeffler (medias)

Genişlik (b) mm	21
Temel statik yük derecesi, radyal (C 0r)	25000
Limiting speed for grease lubrication (n G Grease)	18000

Suffix description

C	15° Or 17° Contact Angle
2RSD	Lip Seals On Both Sides, Non-Contact
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S	Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL	Single Bearing, Universal, Light Preload
L298	High Temperature Grease That, Due To Its Higher Base Oil Viscosity, Is Used At Continuous Temperatures Up To Approx. +110°C
