NSK 7204ATYNDFMP5 Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 3,983.20 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
20 |
| Dış (D) MM |
47 |
| En (B) MM |
28 |
| İç (d) Inch |
0.7874 |
| Dış (D) Inch |
1.8504 |
| En (B) Inch |
1.1024 |
| Ağırlık |
0.2 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Kasa Tipi |
P - Plastik Kalıplı Kafes |
| Kesinlik |
P5 Hassasiyeti (P6dan Yüksek) |
| Contact Angle |
30 degrees |
| Pairing |
DF - X-arrangement, 2 |
| Axial Internal Clearance / Preload |
GB - Medium Preload |
| Yağlama |
Standart Yağlama |
Suffix description
| A |
30° Contact Angle |
| TYN |
This Special Design Allows The Bearing To Have Lower Friction And Lower Noise. The Temperature Rise Of The Bearing With A TYN Cage Is Lower Than That With A Phenolic Cage At A Rotational Speed Lower Than 1.4 Million DmN* ("Dm |
| N |
Pitch Circle Diameter Of Rolling Elements (mm)" x "Speed" (Min-1")) |
| DFM |
Matched Bearing Pair Arranged Face-To-Face, Medium Preload |
| P5 |
Dimensional And Running Accuracy To ISO Tolerance Class 5 |
