INA ZKLR1547-2RS-A Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 4,704.20 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
15 |
| Dış (D) MM |
38,45 |
| En (B) MM |
24 |
| İç (d) Inch |
0.5906 |
| Dış (D) Inch |
1.5138 |
| En (B) Inch |
0.9449 |
| Ağırlık |
0.14 kg
|
Ürün Özellikleri
| Sıkıntı |
C - Silindirik Delik |
| Fok |
2RS - İki Tarafta Kauçuk Conta |
| Kasa Tipi |
S - Çelik veya Standart Kafes |
| Dış Modifikasyon |
Harici Modifikasyon Yok |
| Radyal İç Oyun |
Cn Normal İç Oyun |
| Kesinlik |
Standart Hassasiyet |
| Yağlama |
Standart Yağlama |
| Isı Sabitleme |
Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Split Inner ring / Outer ring |
Split inner ring |
Data from Schaeffler (medias)
| Outside diameter bearing pot (D) mm |
38,45 |
| Radial Static Load Rating C0r (N) |
10700 |
| Width inner ring (B) mm |
22 |
| Radial Dynamic Load Rating Cr (N) |
16700 |
| Axial Static Load Rating C0a (N) |
22400 |
| Axial Dynamic Load Rating Ca (N) |
16400 |
| ECLASS number |
23-05-16-02 |
| ECLASS2 number |
23-05-16-02 |
| Medias description |
Angular contact ball bearing units ZKLR..-2RS, double direction, for screw mounting, lip seals on both sides |
Suffix description
| 2RS |
Lip Seal At Both Sides Of The Bearing, Axial Fitting |
| A |
The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
