INA SL04130-D-PP-2NR-C3-GA22 Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 23,104.00 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
130 |
| Dış (D) MM |
190 |
| En (B) MM |
80 |
| İç (d) Inch |
5.1181 |
| Dış (D) Inch |
7.4803 |
| En (B) Inch |
3.1496 |
| Ağırlık |
7.1 kg
|
Ürün Özellikleri
| Sıkıntı |
C - Silindirik Delik |
| Fok |
2L - Her İki Tarafta LS Contası |
| Kasa Tipi |
FC - Tam Takım, Kafes Yok |
| Dış Modifikasyon |
2R - ODde 2 Snap-ring |
| Radyal İç Oyun |
C3 İç Oyun (Cnden Yüksek) |
| Kesinlik |
Grease -50°C / +120°C |
| Isı Sabitleme |
Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
Data from Schaeffler (medias)
| Genişlik (b) mm |
80 |
| Temel statik yük derecesi, radyal (C 0r) |
790000 |
| Limiting speed for grease lubrication (n G Grease) |
1020 |
Suffix description
| D |
Outer Ring Profile Developed Further, With An Enlarged Load Bearing Area And Optimized Edge Transitions |
| PP |
Lip Seals On Both Sides Of The Bearing |
| 2NR |
Supplied With Two Loose-Packed Retaining Rings WRE |
| C3 |
Internal Clearance Larger Than Normal |
| GA22 |
Optimized Grease For All Purposes, Temperature Range Approximately -50 ~ 120°C - Description: Isoflex® LDS 18 Special A)-Is A Dynamically Light Long-Term Grease For Plain And Rolling Bearings. It Consists Of Ester Oil, Mineral Oil And Lithium Soap. The Product Is Resistant To Ageing, Oxidation And Water, And It Protects Reliably Against Corrosion. Application: Isoflex® LDS 18 Special A Is Suitable For Plain And Rolling Bearings Operating At Low Temperatures And/Or High Speeds, For Example In Grinding Spindles, Machine Tool Spindles, Spindle Bearings, Textile Spindles, Bearings In Oe-Spinning Turbines, Bearings In Precision And Optical Equipment |
