INA NATV15-PP-A Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 876.60 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
15 |
| Dış (D) MM |
35 |
| En (B) MM |
18 |
| İç (d) Inch |
0.5906 |
| Dış (D) Inch |
1.378 |
| En (B) Inch |
0.7087 |
| Ağırlık |
0.098 kg
|
Ürün Özellikleri
| Fok |
2L - Her İki Tarafta LS Contası |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Width of the bearing (B) mm |
19 |
| Basic dynamic load rating, radial (C r w) |
12700 |
| Temel statik yük derecesi, radyal (C 0r) |
23400 |
| Speed on permanent grease lubrication (n D G) |
1600 |
| ECLASS number |
23-05-15-01 |
| ECLASS2 number |
23-05-15-01 |
| Medias description |
Yoke type track rollers NATV..-PP, full complement needle roller set, with axial guidance, axial plain washers on both sides |
Suffix description
| PP |
Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded), Temperature Range -30 ~ 100u2103 |
| A |
Alteration In Internal Construction. Identical To Old Notation |
