INA LR50/7-2RS-HLC Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 654.60 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
7 |
| Dış (D) MM |
22 |
| En (B) MM |
10 |
| İç (d) Inch |
0.2756 |
| Dış (D) Inch |
0.8661 |
| En (B) Inch |
0.3937 |
| Ağırlık |
0.02 kg
|
Ürün Özellikleri
| Fok |
2RS - İki Tarafta Kauçuk Conta |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Height (C) mm |
10 |
| Basic dynamic load rating, radial (C r w) |
3300 |
| Temel statik yük derecesi, radyal (C 0r) |
1700 |
| Speed on permanent grease lubrication (n D G) |
10000 |
| ECLASS number |
23-05-15-90 |
| ECLASS2 number |
23-05-15-90 |
| Medias description |
Track rollers LR50, double row, sealed on both sides |
Suffix description
| 2RS |
Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120u2103 |
| HLC |
Factory Location Code, No Additional Meaning, Can Be Used As Standard |
