INA KWSE35-L-V0-G2 Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 6,419.60 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
34 |
| Dış (D) MM |
100 |
| En (B) MM |
41,4 |
| İç (d) Inch |
1.3386 |
| Dış (D) Inch |
3.937 |
| En (B) Inch |
1.6299 |
| Ağırlık |
2.1 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
100 |
| Overall length carriage (L) mm |
138,9 |
| Dynamic load rating, load direction I: compressive load (I C) |
70000 |
| Static load rating, load direction I: compressive load (I C 0) |
145000 |
| Dynamic load rating, load direction II: tensile load (II C) |
67500 |
| Static load rating, load direction II: tensile load (II C 0) |
119000 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) |
71000 |
| Static load rating, Load direction III: lateral load (III C 0) |
125000 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Long carriage for six-row linear recirculating ball bearing and guideway assembly |
Suffix description
| L |
Long Carriage |
| V0 |
Little To No Preload |
| G2 |
Precision Class 2 |
