INA K28X33X13-B/-1-3 Resim 2

Özellikler

Marka	INA
Ürün No	K28X33X13-B/-1-3 INA
Kategori	İğne Makaralı ve Kafes Tertibatı

Ağırlık ve Boyutlar

İç (d) MM	28
Dış (D) MM	33
En (B) MM	13
İç (d) Inch	1.1024
Dış (D) Inch	1.2992
En (B) Inch	0.5118
Ağırlık	0.015 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Outside diameter of needle roller complement (E w) mm	33
Width (B c) mm	13
Temel statik yük derecesi, radyal (C 0r)	24200
Hız sınırlaması (n G)	16100
Referans Hızı (n u03d1r)	8900
ECLASS number	23-05-09-04
ECLASS2 number	23-05-09-04

Suffix description

B

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

/-1-3

Needle Sort
