INA HK3520-2RS-AS3-L271 Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 421.40 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
35 |
| Dış (D) MM |
42 |
| En (B) MM |
20 |
| İç (d) Inch |
1.378 |
| Dış (D) Inch |
1.6535 |
| En (B) Inch |
0.7874 |
| Ağırlık |
0.041 kg
|
Ürün Özellikleri
| Fok |
2RS - İki Tarafta Kauçuk Conta |
Data from Schaeffler (medias)
| Under roller diameter (F w) mm |
35 |
| Radial Static Load Rating C0r (N) |
33500 |
| Radial Dynamic Load Rating Cr (N) |
18700 |
| Temel statik yük derecesi, radyal (C 0r) |
"33500.0000" |
| Limiting speed for grease lubrication (n G Grease) |
4500 |
| ECLASS number |
23-05-09-05 |
| ECLASS2 number |
23-05-09-05 |
| Medias description |
Drawn cup needle roller bearing open end HK..-2RS-AS3, single row, with cage |
Suffix description
| 2RS |
Lip Seals On Both Sides |
| A |
Needle Roller Bearing, Drawn Cup, Modified Internal Design |
| AS3 |
Needle Roller Bearing With Three Lubrication Holes In The Outer Ring. A Figure Following The As Indicates The Number Of Holes |
| L271 |
Anti Wear Protection Grease |
