INA HFL1426-L564 Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 503.80 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
14 |
| Dış (D) MM |
20 |
| En (B) MM |
26 |
| Ağırlık |
0.015 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Under roller diameter (F w) mm |
14 |
| Radial Static Load Rating C0r (N) |
7800 |
| Radial Dynamic Load Rating Cr (N) |
6800 |
| Temel statik yük derecesi, radyal (C 0r) |
"7800.0000" |
| Limiting speed for rotating shaft (n GW) |
9500 |
| Limiting speed for rotating outer ring (n GA) |
8000 |
| ECLASS number |
23-05-21-90 |
| ECLASS2 number |
23-05-21-90 |
| Medias description |
Drawn cup roller clutch HFL, with bearing |
Suffix description
| L564 |
Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication |
