INA GYE50-KRR-B-FA107 Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 812.60 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
50 |
| Dış (D) MM |
90 |
| En (B) MM |
51,6 |
| İç (d) Inch |
1.9685 |
| Dış (D) Inch |
3.5433 |
| En (B) Inch |
2.0315 |
| Ağırlık |
0.746 kg
|
Ürün Özellikleri
| Fok |
2F - Y-Rulmanlar için Standart Conta |
| Yağlama |
Standart Yağlama |
| Özel Muamele |
I - Lubr Holes on Locating Side |
Data from Schaeffler (medias)
| Outside diameter (D SP) mm |
90 |
| Genişlik (b) mm |
51,6 |
| Radial Static Load Rating C0r (N) |
23200 |
| Radial Dynamic Load Rating Cr (N) |
37500 |
| Temel statik yük derecesi, radyal (C 0r) |
"23200.0000" |
| ECLASS number |
23-05-08-02 |
| ECLASS2 number |
23-05-08-02 |
| Medias description |
Radial insert ball bearing GYE..-KRR-B |
Suffix description
| KRR |
Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B |
Bearing With Spherical Outer Ring |
| FA107 |
Bearing With Lubrication Holes On The Locating Side |
