INA GE60-AW-A Resim 4

Ürüne ait görsel ürün fotoğrafı ve resmi.

Fiyatı: 10,067.80 ₺
Özellikler
Marka INA
Ürün No GE60-AW-A INA
Üretici No 0066518360000
Alternatif Kodu GX60F
EAN 4012802532715
Kategori Küresel Düz Yatak
Ağırlık ve Boyutlar
İç (d) MM 60
Dış (D) MM 150
En (B) MM 45
İç (d) Inch 2.3622
Dış (D) Inch 5.9055
En (B) Inch 1.7717
Ağırlık 4.4 kg
Ürün Özellikleri
Fok Kapaksız
Contact Material Steel on PTFE
Data from Schaeffler (medias)
Outside diameter bearing (D) mm 150
Height (T) mm 45
Width inner ring (B) mm 37
Axial Static Load Rating C0a (N) 3680000
Axial Dynamic Load Rating Ca (N) 2210000
ECLASS number 23-05-01-06
ECLASS2 number 23-05-01-06
Medias description Axial spherical plain bearing, maintenance-free, DIN ISO 12240-3, shaft location washer curved surface with hard chromium coating, open design
Suffix description
AW Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene))
A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
