INA GE55-SW-A Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 8,028.20 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
55 |
| Dış (D) MM |
90 |
| En (B) MM |
23 |
| İç (d) Inch |
2.1654 |
| Dış (D) Inch |
3.5433 |
| En (B) Inch |
0.9055 |
| Ağırlık |
0.69 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
90 |
| Height (T) mm |
23 |
| Radial Static Load Rating C0r (N) |
746000 |
| Width inner ring (B) mm |
22 |
| Radial Dynamic Load Rating Cr (N) |
448000 |
| Temel statik yük derecesi, radyal (C 0r) |
"746000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Angular contact spherical plain bearing, maintenance-free, DIN ISO 12240-2, inner ring curved surface with hard chromium coating, open design |
Suffix description
| SW |
Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene)) |
| A |
Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard) |
