INA GE110-SX Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 24,563.20 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
110 |
| Dış (D) MM |
170 |
| En (B) MM |
38 |
| İç (d) Inch |
4.3307 |
| Dış (D) Inch |
6.6929 |
| En (B) Inch |
1.4961 |
| Ağırlık |
3.9 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Contact Material |
Steel on Steel |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
170 |
| Height (T) mm |
38 |
| Radial Static Load Rating C0r (N) |
2340000 |
| Radial Dynamic Load Rating Cr (N) |
469000 |
| Temel statik yük derecesi, radyal (C 0r) |
"2340000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Angular contact spherical plain bearing, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-2, open design |
Suffix description
| SX |
Angular Contact Spherical Plain Bearing Requiring Maintenance To Iso 12 2402, Mounting Dimensions As For Tapered Roller Bearings To Din 720, 320X, Sliding Contact Surface Steel/Steel |
