INA GAL20-UK Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 1,055.20 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
20 |
| Dış (D) MM |
54 |
| En (B) MM |
16 |
| İç (d) Inch |
0.7874 |
| Dış (D) Inch |
2.126 |
| En (B) Inch |
0.6299 |
| Ağırlık |
0.28 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
35 |
| Outer eye diameter (d 2) mm |
53 |
| Radial Static Load Rating C0r (N) |
75600 |
| Width inner ring (B) mm |
16 |
| Radial Dynamic Load Rating Cr (N) |
31300 |
| Temel statik yük derecesi, radyal (C 0r) |
"75600.0000" |
| Total length external thread rod (l 2) mm |
104,5 |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Rod end with external thread, left hand thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, open design |
Suffix description
| UK |
Sliding Contact Surface Hard Chromium/PTFE Composite |
