INA GAKL5-PB-A Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 720.80 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
5 |
| Dış (D) MM |
18 |
| En (B) MM |
8 |
| İç (d) Inch |
0.1969 |
| Dış (D) Inch |
0.7087 |
| En (B) Inch |
0.315 |
| Ağırlık |
0.013 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Contact Material |
Steel on Bronze |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
13 |
| Radial Static Load Rating C0r (N) |
4900 |
| Width inner ring (B) mm |
8 |
| Radial Dynamic Load Rating Cr (N) |
3330 |
| Temel statik yük derecesi, radyal (C 0r) |
"4900.0000" |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Rod end with external thread, left hand thread, requiring maintenance, sliding contact surface: steel/bronze, DIN ISO 12240-4, dimension series K, type M, open design |
Suffix description
| PB |
Sliding Contact Surface Is Steel/Bronze |
| A |
The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
