FAG HC7014-EDLR-T-P4S-UL Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 14,474.80 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
70 |
| Dış (D) MM |
110 |
| En (B) MM |
20 |
| İç (d) Inch |
2.7559 |
| Dış (D) Inch |
4.3307 |
| En (B) Inch |
0.7874 |
| Ağırlık |
0.61 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Kasa Tipi |
TB - Sert Fiber Kafes |
| Kesinlik |
P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle |
25 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Yağlama |
DLR |
Data from Schaeffler (medias)
| Genişlik (b) mm |
20 |
| Radial Static Load Rating C0r (N) |
15600 |
| Radial Dynamic Load Rating Cr (N) |
23700 |
| Temel statik yük derecesi, radyal (C 0r) |
"15600.0000" |
| Limiting speed for grease lubrication (n G Grease) |
20000 |
| Limiting speed for oil lubrication (n G Oil) |
32000 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
Suffix description
| E |
25° Contact Angle |
| DLR |
Direct Lube, Integral O-Ring |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S |
Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UL |
Single Bearing, Universal, Light Preload |
