FAG F522-B-L Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 13,204.00 ₺
Özellikler
Ağırlık ve Boyutlar
| Dış (D) MM |
270 |
| En (B) MM |
128 |
| Dış (D) Inch |
10.6299 |
| En (B) Inch |
5.0394 |
| Ağırlık |
22.2 kg
|
Data from Schaeffler (medias)
| Shaft diameter (d 1) mm |
100 |
| Flange width (a) mm |
270 |
| Height flange (h 1) mm |
270 |
| Total width with cover (g 2) mm |
137 |
| Number of fastening holes |
4 |
| ECLASS number |
23-05-17-02 |
| ECLASS2 number |
23-05-17-02 |
| Medias description |
Flanged housing for various bearing types, with conical bore and clamping sleeve, continuous shaft |
Suffix description
| B |
Open Ends On Both Sides Of The Housing |
| L |
Flake Graphite Cast Iron (Standard) |
