FAG F511-WA-L Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 4,443.60 ₺
Özellikler
Ağırlık ve Boyutlar
| Dış (D) MM |
190 |
| En (B) MM |
71 |
| Dış (D) Inch |
7.4803 |
| En (B) Inch |
2.7953 |
| Ağırlık |
4.2 kg
|
Data from Schaeffler (medias)
| Shaft diameter (d 1) mm |
50 |
| Flange width (a) mm |
190 |
| Height flange (h 1) mm |
170 |
| Total width with cover (g 2) mm |
77 |
| Number of fastening holes |
3 |
| ECLASS number |
23-05-17-02 |
| ECLASS2 number |
23-05-17-02 |
| Medias description |
Flanged housing for various bearing types, wide version with conical bore and clamping sleeve, closed on one side |
Suffix description
| W |
Plummer Block Housings, Non-Split For Wide Bearings |
| A |
One Side Closed |
| L |
Flake Graphite Cast Iron (Standard) |
