FAG F510-A-L Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 3,678.20 ₺
Özellikler
Ağırlık ve Boyutlar
| Dış (D) MM |
180 |
| En (B) MM |
65 |
| Dış (D) Inch |
7.0866 |
| En (B) Inch |
2.5591 |
| Ağırlık |
3.3 kg
|
Data from Schaeffler (medias)
| Shaft diameter (d 1) mm |
45 |
| Flange width (a) mm |
180 |
| Height flange (h 1) mm |
160 |
| Total width with cover (g 2) mm |
65 |
| Number of fastening holes |
3 |
| ECLASS number |
23-05-17-02 |
| ECLASS2 number |
23-05-17-02 |
| Medias description |
Flanged housing for various bearing types, with conical bore and clamping sleeve, closed on one side |
Suffix description
| A |
One End Closed |
| L |
Grey Cast Iron |
