FAG F509-WB-L Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 2,596.40 ₺
Özellikler
Ağırlık ve Boyutlar
| Dış (D) MM |
180 |
| En (B) MM |
65 |
| Ağırlık |
3.6 kg
|
Data from Schaeffler (medias)
| Shaft diameter (d 1) mm |
40 |
| Flange width (a) mm |
180 |
| Height flange (h 1) mm |
160 |
| Total width with cover (g 2) mm |
74 |
| Number of fastening holes |
3 |
| ECLASS number |
23-05-17-02 |
| ECLASS2 number |
23-05-17-02 |
| Medias description |
Flanged housing for various bearing types, wide version with conical bore and clamping sleeve, continuous shaft |
Suffix description
| W |
Plummer Block Housings, Non-Split For Wide Bearings |
| B |
Open On Both Sides |
| L |
Flake Graphite Cast Iron (Standard) |
