FAG F508-WB-L Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 1,956.80 ₺
Özellikler
Ağırlık ve Boyutlar
| Dış (D) MM |
160 |
| En (B) MM |
65 |
| Ağırlık |
2.7 kg
|
Data from Schaeffler (medias)
| Shaft diameter (d 1) mm |
35 |
| Flange width (a) mm |
160 |
| Height flange (h 1) mm |
143 |
| Total width with cover (g 2) mm |
71 |
| Number of fastening holes |
3 |
| ECLASS number |
23-05-17-02 |
| ECLASS2 number |
23-05-17-02 |
| Medias description |
Flanged housing for various bearing types, wide version with conical bore and clamping sleeve, continuous shaft |
Suffix description
| W |
Plummer Block Housings, Non-Split For Wide Bearings |
| B |
Open On Both Sides |
| L |
Flake Graphite Cast Iron (Standard) |
