FAG B7202-C-T-P4S-DUL Resim 2

Ürüne ait görsel ürün fotoğrafı ve resmi.

Fiyatı: 5,159.00 ₺
Özellikler
Marka FAG
Ürün No B7202-C-T-P4S-DUL FAG
Üretici No 0380478100000
Alternatif Kodu 7202CD/P4ADGA
EAN 4012801619011
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 15
Dış (D) MM 35
En (B) MM 22
İç (d) Inch 0.5906
Dış (D) Inch 1.378
En (B) Inch 0.8661
Ağırlık 0.08 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload DL - 2 Univ Bearings Light Preload
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 11
Radial Static Load Rating C0r (N) 5000
Radial Dynamic Load Rating Cr (N) 11600
Temel statik yük derecesi, radyal (C 0r) "5000.0000"
Limiting speed for grease lubrication (n G Grease) 45000
Limiting speed for oil lubrication (n G Oil) 67000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B72..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
DUL Set Of 2 Universal Bearings, Light Preload
