FAG B71912-E-2RSD-T-P4S-K5-UM Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 7,957.00 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
60 |
| Dış (D) MM |
85 |
| En (B) MM |
13 |
| İç (d) Inch |
2.3622 |
| Dış (D) Inch |
3.3465 |
| En (B) Inch |
0.5118 |
| Ağırlık |
0.2 kg
|
Ürün Özellikleri
| Fok |
2RU - İki Conta / Temassız Tip |
| Kasa Tipi |
TB - Sert Fiber Kafes |
| Kesinlik |
K5 - P4S + K5 |
| Contact Angle |
25 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements |
| Yağlama |
Standart Yağlama |
Data from Schaeffler (medias)
| Genişlik (b) mm |
13 |
| Temel statik yük derecesi, radyal (C 0r) |
15200 |
| Limiting speed for grease lubrication (n G Grease) |
14000 |
Suffix description
| E |
25° Contact Angle |
| 2RSD |
Lip Seals On Both Sides, Non-Contact |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S.K5 |
Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter) |
| UM |
Single Bearing, Universal, Medium Preload |
