FAG B7021-C-T-P4S-UL Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 12,334.40 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
105 |
| Dış (D) MM |
160 |
| En (B) MM |
26 |
| İç (d) Inch |
4.1339 |
| Dış (D) Inch |
6.2992 |
| En (B) Inch |
1.0236 |
| Ağırlık |
1.52 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Kasa Tipi |
TB - Sert Fiber Kafes |
| Kesinlik |
P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle |
15 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Yağlama |
Standart Yağlama |
Data from Schaeffler (medias)
| Genişlik (b) mm |
26 |
| Radial Static Load Rating C0r (N) |
61000 |
| Radial Dynamic Load Rating Cr (N) |
85000 |
| Temel statik yük derecesi, radyal (C 0r) |
"61000.0000" |
| Limiting speed for grease lubrication (n G Grease) |
8500 |
| Limiting speed for oil lubrication (n G Oil) |
13000 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Spindle bearings B70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances |
Suffix description
| C |
15° Or 17° Contact Angle |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S |
Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UL |
Single Bearing, Universal, Light Preload |
