SKF 7008FEGA/HCP4A
Fiyatı: 10,108.80 ₺
Özellikler
| Marka | SKF |
| Ürün No | 7008FEGA/HCP4A SKF |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 40 |
| Dış (D) MM | 68 |
| En (B) MM | 15 |
| İç (d) Inch | 1.5748 |
| Dış (D) Inch | 2.6772 |
| En (B) Inch | 0.5906 |
| Ağırlık | 0.17 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | H4 - Hibrit / Seramik Toplar / P4 |
| Contact Angle | 18 degrees - 18° Cont. High Speed E Design |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | GA - Light Preload |
| Yağlama | Standart Yağlama |
| FE | 18° Contact Angle, High-Speed E-design |
| GA | Single Row Angular Contact Ball Bearing For Universal Matching. Two Bearings Arranged Back-To-Back Or Face-To-Face Will Have A Light Preload |
| HC | Bearing Or Bearing Components Of Ceramic |
| P4A | Dimensional Accuracy In Accordance With ISO Tolerance Class 4, Running Accuracy Better Than ISO Tolerance Class 4 |
