INA VSU200414-VSP-ZT

Özellikler

Marka	INA
Ürün No	VSU200414-VSP-ZT INA
Üretici No	0003518220000
EAN	4054365629037
Kategori	Döndürme

Ağırlık ve Boyutlar

İç (d) MM	342
Dış (D) MM	486
En (B) MM	56
Ağırlık	29 kg

Data from Schaeffler (medias)

Outside Diameter (D a) mm	486
Width inner ring (h i) mm	44,5
Width outer ring (h a) mm	44,5
ECLASS number	23-05-14-90
ECLASS2 number	23-05-14-90

Suffix description

VSP	For Mounting With An Axially Supported L-Section Ring In Series YRT. In Fitting Of The Series YRT With An L-Section Ring Supported Axially Over Its Whole Surface, There Is An Increase In The Axial Rigidity In The Direction Of The Support Ring As A Function Of The Support Ring Rigidity And In The Tilting Rigidity Of Up To 20%. In This Case, Delivery With A Different Preload Match Is Necessary
ZT	Centring On Inner And Outer Rings
