INA VLA200544-N-VSP-ZT

Özellikler

Marka	INA
Ürün No	VLA200544-N-VSP-ZT INA
Üretici No	0511726900000
EAN	4047643203067
Kategori	Döndürme

Ağırlık ve Boyutlar

İç (d) MM	434
Dış (D) MM	640,3
En (B) MM	56
İç (d) Inch	17.0866
Dış (D) Inch	25.2087
En (B) Inch	2.2047
Ağırlık	41.5 kg

Data from Schaeffler (medias)

Outside Diameter (D a) mm	640,3
ECLASS number	23-05-14-90
ECLASS2 number	23-05-14-90

Suffix description

N	Normalized Gear Teeth On Bearing Ring
VSP	For Mounting With An Axially Supported L-Section Ring In Series YRT. In Fitting Of The Series Yrt With An L-Section Ring Supported Axially Over Its Whole Surface, There Is An Increase In The Axial Rigidity In The Direction Of The Support Ring As A Function Of The Support Ring Rigidity And In The Tilting Rigidity Of Up To 20%. In This Case, Delivery With A Different Preload Match Is Necessary
ZT	Centring On Inner And Outer Rings
