INA SX011840-A-VSP+PRL50
Fiyatı: 71,566.40 ₺
Özellikler
| Marka | INA |
| Ürün No | SX011840-A-VSP+PRL50 INA |
| Üretici No | 0071374002301 |
| EAN | 4054366267993 |
| Kategori | Özel Ürünler |
| İç (d) MM | 200 |
| Dış (D) MM | 250 |
| En (B) MM | 24 |
| Ağırlık | 3.1 kg |
| Outside Diameter (D a) mm | 250 |
| Height of the assembled bearing (H) mm | 24 |
| ECLASS number | 23-05-12-05 |
| ECLASS2 number | 23-05-12-05 |
| A | |
| VSP | For Mounting With An Axially Supported L-Section Ring In Series YRT. In Fitting Of The Series Yrt With An L-Section Ring Supported Axially Over Its Whole Surface, There Is An Increase In The Axial Rigidity In The Direction Of The Support Ring As A Function Of The Support Ring Rigidity And In The Tilting Rigidity Of Up To 20%. In This Case, Delivery With A Different Preload Match Is Necessary |
| PRL50 | For YRT, Axial And Radial Runout Tolerance Restricted By 50% (Additional Text: Axial/Radial Runout 50%) |
