INA SX011832-A-VSP

Özellikler

Marka	INA
Ürün No	SX011832-A-VSP INA
Üretici No	0071373890079
EAN	4012802136494
Kategori	Özel Ürünler

Ağırlık ve Boyutlar

İç (d) MM	160
Dış (D) MM	200
En (B) MM	20
İç (d) Inch	6.2992
Dış (D) Inch	7.874
En (B) Inch	0.7874
Ağırlık	1.7 kg

Data from Schaeffler (medias)

Outside Diameter (D a) mm	200
Height of the assembled bearing (H) mm	20
ECLASS number	23-05-12-05
ECLASS2 number	23-05-12-05

Suffix description

A
VSP	For Mounting With An Axially Supported L-Section Ring In Series YRT. In Fitting Of The Series Yrt With An L-Section Ring Supported Axially Over Its Whole Surface, There Is An Increase In The Axial Rigidity In The Direction Of The Support Ring As A Function Of The Support Ring Rigidity And In The Tilting Rigidity Of Up To 20%. In This Case, Delivery With A Different Preload Match Is Necessary
