INA SX0118/500-VSP

INA SX0118/500-VSP
INA SX0118/500-VSP rulman resim 1
INA SX0118/500-VSP rulman resim 2
Fiyatı: 0.00 ₺
Özellikler
Marka INA
Ürün No SX0118/500-VSP INA
Üretici No 0011775670079
EAN 4054365914799
Kategori Özel Ürünler
Ağırlık ve Boyutlar
İç (d) MM 500
Dış (D) MM 620
En (B) MM 56
Ağırlık 42.9 kg
Data from Schaeffler (medias)
Outside Diameter (D a) mm 620
Height of the assembled bearing (H) mm 56
ECLASS number 23-05-12-05
ECLASS2 number 23-05-12-05
Suffix description
VSP For Mounting With An Axially Supported L-Section Ring In Series YRT. In Fitting Of The Series YRT With An L-Section Ring Supported Axially Over Its Whole Surface, There Is An Increase In The Axial Rigidity In The Direction Of The Support Ring As A Function Of The Support Ring Rigidity And In The Tilting Rigidity Of Up To 20%. In This Case, Delivery With A Different Preload Match Is Necessary
