INA SL185056-TB-BR

Fiyatı: 0.00 ₺
Özellikler
Marka INA
Ürün No SL185056-TB-BR INA
Üretici No 0535308530000
EAN 4047643141338
Kategori Silindirik Makaralı - Çift Sıra
Ağırlık ve Boyutlar
İç (d) MM 280
Dış (D) MM 420
En (B) MM 190
Ağırlık 90.5 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Fok Kapaksız
Kasa Tipi FC - Tam Takım, Kafes Yok
Dış Modifikasyon Harici Modifikasyon Yok
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik BR - Siyah Kaplama
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Data from Schaeffler (medias)
Genişlik (b) mm 190
Temel statik yük derecesi, radyal (C 0r) 5300000
Hız sınırlaması (n G) 900
Referans Hızı (n u03d1r) 460
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Suffix description
TB In The Case Of Bearings Of TB Design, The Axial Load Carrying Capacity Of Cylindrical Roller Bearings Was Significantly Improved With The Aid Of New Calculation And Manufacturing Methods. Optimum Contact Conditions Between The Roller And Rib Are Ensured By Means Of A Special Curvature Of The Roller End Faces. As A Result, The Axial Contact Pressures On The Rib Are Significantly Minimised And A Lubricant Film Capable Of Supporting Higher Loads Is Formed. Under Normal Operating Conditions, Wear And Fatigue At The Rib Contact Running And Roller End Faces Is Completely Eliminated. In Addition, Axial Frictional Torque Is Reduced By Up To 50%. The Bearing Temperature During Operation Is Therefore Significantly Lower
BR Black Finished, Factory-Applied Durotect® B Black-Oxide Coating. Durotect B Improves Run-In Behavior And Energy Efficiency While Reducing Surface-Induced Damage To The Bearing, Burnished Race
