INA PWKR40-2RS-RR-XL

Özellikler

Marka	INA
Ürün No	PWKR40-2RS-RR-XL INA
Üretici No	0541300260000
Alternatif Kodu	PWKR40-2RS-RR
EAN	4054366739681
Kategori	Kam Takipçisi

Ağırlık ve Boyutlar

İç (d) MM	18
Dış (D) MM	40
En (B) MM	20
İç (d) Inch	0.7087
Dış (D) Inch	1.5748
En (B) Inch	0.7874
Ağırlık	0.242 kg

Ürün Özellikleri

Fok	2RS - İki Tarafta Kauçuk Conta
Excenterring	Other Mounting Method
Running Surface	Standard

Data from Schaeffler (medias)

Fit diameter of roller stud / stud (d 1) mm	18
Genişlik (b) mm	58
Basic dynamic load rating, radial (C r w)	14300
Temel statik yük derecesi, radyal (C 0r)	18200
Speed on permanent grease lubrication (n D G)	5000
ECLASS number	23-05-15-02
ECLASS2 number	23-05-15-02
Medias description	Stud type track rollers PWKR..-2RS-RR, With axial guidance, full complement cylindrical roller set, lip seal on both sides, with Corrotect coating

Suffix description

2RS	Rubber Seals At Each Side Of The Bearing, Temperature Range -30u2103/+120u2103
RR	Protected Against Corrosion By Corrotect® Special Coating
XL	X-Life
