INA LSL192332-TB-N1-C3
Fiyatı: 179,669.40 ₺
Özellikler
| Marka | INA |
| Ürün No | LSL192332-TB-N1-C3 INA |
| Kategori | Silindirik Makaralı - Tek Sıra |
| İç (d) MM | 160 |
| Dış (D) MM | 340 |
| En (B) MM | 114 |
| İç (d) Inch | 6.2992 |
| Dış (D) Inch | 13.3858 |
| En (B) Inch | 4.4882 |
| Ağırlık | 48.1 kg |
| Sıkıntı | C - Silindirik Delik |
| Fok | Kapaksız |
| Kasa Tipi | S - Çelik veya Standart Kafes |
| Dış Modifikasyon | N1 - Dış Halkada 1 Kilitleme Oluğu |
| Radyal İç Oyun | C3 İç Oyun (Cnden Yüksek) |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| TB | In The Case Of Bearings Of TB Design, The Axial Load Carrying Capacity Of Cylindrical Roller Bearings Was Significantly Improved With The Aid Of New Calculation And Manufacturing Methods. Optimum Contact Conditions Between The Roller And Rib Are Ensured By Means Of A Special Curvature Of The Roller End Faces. As A Result, The Axial Contact Pressures On The Rib Are Significantly Minimised And A Lubricant Film Capable Of Supporting Higher Loads Is Formed. Under Normal Operating Conditions, Wear And Fatigue At The Rib Contact Running And Roller End Faces Is Completely Eliminated. In Addition, Axial Frictional Torque Is Reduced By Up To 50%. The Bearing Temperature During Operation Is Therefore Significantly Lower |
| N1 | One Locating Slot (Notch) In One Outer Ring Side Face Or Housing Washer |
| C3 | Internal Clearance Larger Than Normal |
