INA LR5003-2RS

Özellikler

Marka	INA
Ürün No	LR5003-2RS INA
Üretici No	0008170400000
EAN	4012802782103
Kategori	Destek Silindiri

Ağırlık ve Boyutlar

İç (d) MM	17
Dış (D) MM	40
En (B) MM	14
İç (d) Inch	0.6693
Dış (D) Inch	1.5748
En (B) Inch	0.5512
Ağırlık	0.07 kg

Ürün Özellikleri

Fok	2RS - İki Tarafta Kauçuk Conta
Running Surface	Standard

Data from Schaeffler (medias)

Height (C) mm	14
Basic dynamic load rating, radial (C r w)	7800
Temel statik yük derecesi, radyal (C 0r)	5400
Speed on permanent grease lubrication (n D G)	6000
ECLASS number	23-05-15-90
ECLASS2 number	23-05-15-90
Medias description	Track rollers LR50, double row, sealed on both sides

Suffix description

2RS	Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120u2103
