INA KWVE35-B-L-V0-G4
Fiyatı: 3,835.40 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE35-B-L-V0-G4 INA |
| Üretici No | 0174213730150 |
| Alternatif Kodu |
KWVE35-B-L-G4-V0 |
| EAN | 4054366325297 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 34 |
| Dış (D) MM | 100 |
| En (B) MM | 145 |
| İç (d) Inch | 1.3386 |
| Dış (D) Inch | 3.937 |
| En (B) Inch | 5.7087 |
| Ağırlık | 2.52 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 100 |
| Overall length carriage (L) mm | 145 |
| Dynamic load rating (C) | 47500 |
| Static load rating (C 0) | 100000 |
| Static moment rating about X axis (M 0x) | 2625 |
| Static moment rating about Y axis (M 0y) | 1890 |
| Static moment rating about Z axis (M 0z) | 1890 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-L, long carriage, four-row, full complement ball set |
| B | Version |
| L | Long Carriage |
| V0 | Little To No Preload |
| G4 | Precision Class 4 |
