INA KWVE20-B-EC-V2-G4
Fiyatı: 1,842.80 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE20-B-EC-V2-G4 INA |
| Üretici No | 0125089420350 |
| Alternatif Kodu |
KWVE20-B-EC-G4-V2 |
| EAN | 4054362967620 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 20 |
| Dış (D) MM | 59 |
| En (B) MM | 50,4 |
| İç (d) Inch | 0.7874 |
| Dış (D) Inch | 2.3228 |
| En (B) Inch | 1.9843 |
| Ağırlık | 0.23 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 59 |
| Overall length carriage (L) mm | 50,4 |
| Dynamic load rating (C) | 8900 |
| Static load rating (C 0) | 15400 |
| Static moment rating about X axis (M 0x) | 190 |
| Static moment rating about Y axis (M 0y) | 85 |
| Static moment rating about Z axis (M 0z) | 85 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-EC, expanded interchangeability, short carriage, four-row |
| B | Version |
| EC | Expanded Design, Short Carriage (Carriage Without Screw Threads) |
| V2 | Preload Class 2 |
| G4 | Precision Class 4 |
